Ejector Sleeves Φ3.401+0.008xΦ3.70xΦ12×250.46mm
- Material: 1.2343 with 50HRC
- Dimension: Φ0.570-0.005xΦ1.000-0.005Φ1.80-0.05×63.50mm
- Processing Procudures: Rough Turning→ Heat Treatment→Centerless Grinding→ Forming Grinding→ Face Grinding→ Fine Polishing
- Processing Difficulties: External diameter Φ0.570-0.005 too tin to deform during forming grinding
- Measuring methods: Micrometer capllier
- Application: plastic injection molds
